DM-8 TTR Ribbon

DM-8 Mixed Base Carbon Ribbon has excellent friction resistance, corrosion resistance, and a wide range of application.
The high-resolution performance is suitable for high-performance printers and simple type printers in various industrial and commercial fields ,and the high sensitivity ensures excellent printing effect.Anti-static coating effectively protects the print head.
Applying to electronic tags, gardening timber, drug labels, the automotive industry, logistics tracking, retail labels and tags.
Specific and good compatibility, ultra-low-energy level, scratch resistance, low noise, higher definition, etc.
DM-8 Mixed Base Carbon Ribbon is with high-quality friction resistance, corrosion resistance, and a wide range of application.
The high-resolution performance is suitable for high-performance printers and simple type printers in various industrial and commercial fields ,and the high sensitivity ensures excellent printing effect. Anti-static coating effectively protects the print head.

Specifications
Model	Ribbon Material	Suitable Material
DM-801	Wax	Ordinary coated paper
DM-802	Premium Wax-Resin	Coated paper
DM-803	Premium Wax-Resin	Coated paper
DM-804	Wax-Resin	Electronic tags, special smooth and not easy adherent material
DM-805	Resin

Parameters:

Carbon Thickness	7.3±0.3 μm
Ink Thickness	3.0±0.2 μm
Electrostatic	≤0.03 kv
Optical Density	≥1.5 D
Color Density	≥2.1 DB
Printing Speed	12 IPS
Melting Point	80℃
Applicable Medium	Coated paper,synthetic paper, label paper,coated paper,polyethylene(PE),polyethylene(PET)
